Max Lift Capacity: 12,000 lb Max Lift Height: 55 ft Max Forward Reach: 42 ft Lift Capacity at Max Height: 5,000 lb Lift Capacity at Max Reach: 3,500 lb Frame Leveling: 10° Lift Speed (retracted boom): Up 16 sec, Down 13 sec Boom Speed: Extend 18 sec, Retract 15 sec Top Travel Speed: 20 mph Drawbar Pull (loaded): 25,400 lb Outside Turning Radius: 14 ft Operating Weight: 33,960 lb Engine: Cummins QSF3.8L, 4-cylinder, Tier 4 Final, 130 hp Fuel Tank: 38.3 gal Transmission: Powershift, 4-speed forward, 3-speed reverse Axles: Trunnion-mounted planetary, 45° steer, high-bias limited-slip front differential Brakes: Wet inboard disc front/rear, spring-applied parking brake Tire Size: 400/75-28 (foam-filled or solid optional) Cab: Certified ROPS/FOPS, adjustable seat, single-joystick controls with tilt and declutch, horn, anti-theft Steering: Hydraulic power; selectable 2-wheel front, 4-wheel circle, 4-wheel crab Auxiliary Hydraulics: Load-sense piston pump, 49.9 gal capacity Dimensions: Length: 20.11 ft Width: 8.5 ft Height: 8.4 ft Ground Clearance: 1.6 ft Wheelbase: 11.6 ft
